Mounting drives in the Master Caddy II

Insert the disk into the caddy, and secure with four screws. The caddy is light and the disk just needs to be held securely. Don’t over-tighten the screws. There are no connections to make because sliding the caddy into the Sumo19 or the Docking station makes all the connections for you.

The Master Caddy can’t be inserted the wrong way round. Always make sure that the disk connector faces the slot in the Sumo19. You have to be quite firm to push the Master Caddy II into place, but don’t push too hard, just in case something isn’t set up or aligned properly.

There is very little that can cause problems and the most likely thing is that the Master Caddy isn’t properly flush with the drive inside. A quick visual check will confirm this.

Spinning disks and SSDs are very sensitive to damage from static electricity. Please observe all the usual precautions

when handling them, especially DO NOT EVER touch the exposed SATA connector as static electricity may be harmful

to your disk.

Do not over-tighten screws or alignment can not be guaranteed. We suggest squeezing the corners together near the screw you are tightening for optimal fit.
